1550nm 2mW DFB Coaxial Laser Diode For Fiber Optical Equipment

(No reviews yet) Write a Review
  • 1550nm 2mW DFB Coaxial Laser Diode For Fiber Optical Equipment
  • 1550nm 2mW DFB Coaxial Laser Diode For Fiber Optical Equipment
  • 1550nm 2mW DFB Coaxial Laser Diode For Fiber Optical Equipment
  • 1550nm 2mW DFB Coaxial Laser Diode For Fiber Optical Equipment
$126.00

Description

Features:

Coaxial pigtailpackage;

Built-in InGaAs/PINmonitor;

Integrated opticalisolator;

Operating temperature range: -20 to80℃


Applications:

CDMA/GSM transmissionsystem;

WDMsystem;

CATVReturn-path;

Other analog transmission system.



Parameter

Symbol

Condition

Min.

Typ.

Max.

Unit

 Center wavelength

λ

-

-

1310 or 1550

-

nm

 Optical output power

Pf

If=Ith+20mA

2

-

-

mW

 Threshold current

Ith


4


10

mA

 Operating voltage

Vf

-


1.2

1.5

V

 Rise time/Fall time


IF=ITH,PO=PF(20-80)%

-

-

0.4

ns

 Monitor current


PO=PF

0.1

-

1

mA


Pin Definition:
