Features:

This product is designed to boost multiple users with maximum power. It is best used in the following applications:

1. GSM/EGSM/CDMA800/3G/WLAN/WiMax

2. Wireless Communications and data transmission system Repeater

3. Omni-directional use for indoor

Attention:

1. This is an indoor Omni-directional antenna only. It doesn't work alone. You need a Cell Phone Signal Booster/Repeater to work with this antenna.

2. This indoor directional antenna is designed together with the cable , in order to reduce the loss of the signal and it can be installed easily .

Specification:

1.Model No.:SB-CI-1

2.Frequency range:698-2700MHZ

3.Gain:3dbi

4.VSWR: Under 1.5

5.Vertical polarization

6.Omni antenna

7.F/B ratio: less than18dB

8.Polarization:Vertical

9.Max power:100 W

10.Nominal Impedance:50 OHM

11.Connector:N Female

12.Dimension:180x90mm

13.Weight:550 g

14.Rated wind velocity: 60m/s

15.Match up with N female gsm cdma pcs dcs wcdma 3g signal repeater

16.Cabel Impedance: 75OHM

Package Contents:

1 x Ceiling Indoor Omni-directional Antenna

1 x 3m/5m cable with N male connector

Note:

The Cable has white and black,if you don't leave message what color you need,then we choose random to ship.Enjoying your shopping.

Indoor Ceiling Antenna GSM/3G 698-2700Mhz 5dBi 5m Cable N Male for GSM 3G Cell Phone Signal Booster Repeater Amplifier

Real item Details:
