Description

Processor Performance for referance only

What In The Package

1x Mini PC

1x AC adapter ( we ship correct power plug base on buyer's address )

1x Power cord

1x WiFi module and antennas ("NO SSD NO RAM" bundle package without WiFi module and antennas )

1x SATA Power cable & data cable

1 x User manaul & warranty card

Note:

1.Barebone Mini PC ("No Ram No HD No WiFi" bundle) package DO NOT include WiFi(antennas),

if you need, please pay extra $6 for WIFI.at this link.If you need help,pls contact us.

2.All industrial computers with4/6 coms in this shop do not have WiFi by default.

3. DO NOT buy Barebone Mini PC ("No Ram No HD No WiFi" bundle) If you are NOT IT hardware technician.

PC demands professional skill to assemble.We DO NOT compensate for buyer's man-made damage and faulty.

8th/10th/11th/12th Gen 2xDDR4 SO-DIMM Ram slot ,Max 64GB

Basic Information:
CPU	Intel Core i5-8250u/I7 8550U/10510U
TDP	15W
BOIS	AMI BIOS, ACPI supported
Chipset	IntelKABYLAKE
Memory	2xSO-DIMMDDR4Slot Support8GB/16GB/32GB Dual Channel, DDR4-2400, LPDDR3-2133
OS	Windows 7/Windows 8/Windows 10/Linux
PXE	YES
Audio	ALC897 chip, 7.1 channel sound Intel Lynx Point-LP HDA
Network	Onboard Realtek RTL8168/8111/8112PCI-E Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN
Video	Intel®UHDGraphics620
Input/output port
Switch	1 x Power On/Off Switch
Power	1 x 12V DC In
LED	1 x LED
USB	3 x USB2.0, 4 xUSB3.0
Display	1 x VGA, 1 x HDMI
LAN	1 x RJ45 Giga LAN
COM	2 xRS232 COM
Audio	1 x MIC, 1 x SPK
Storage
MSATA	1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s 1xM.2slot for M.2 SSD, support 6Gb/s
SATA	1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s
Wi-Fi
Module	1 x mini PCIE-half port for Wi-Fi module
Antenna	2 x inner RF cables and 2 x external antennas
Power and Working Environment
Input	DC100-240V AC/50-60Hz
Output	DC +12V~+19V, recommend 12V/5A
Operating Temperature	0/+70 Centigrade
Storage Temperature	-20/+85 Centigrade
Relative Humidity	0%~90% (non-condensing)
Product Dimension & Details
Size	23415043mm
Weight	Net1.8kg, Gross2.1kg
Shell	Blackcolor aluminum alloy
Mounting	4 Mounting holes on case
Cooling Mode	Fanless
Functions	Calls on function automatically,Wake-On-LAN
Package Content
Standard	1xMini PC,1xPowerAdapter,1xPower Cord,1xScrewsBag
Optional	Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xLong Screws Bag
