Description
this access controller is adopted the Newest 32-bit ARM cpu, it have very stronger fucntion. Its main function include: Attendance / Access control / Access alarm / Fingerpint / Web function / cell phone .
Attendance :support normal shif rules and Multi-shif rules ,this can meet variety of attendance needed.
Access control:suport Time profile / password manage / anti-passback / inter lock / first card / task list .
Access alarm:suport door open too long warm / door forced open / invalid card / fire alarm / Threat code / force lock
web function:suport PC,tablet ,cell phone use IE or Chrome browser etc.
Main parameters
Model:L01
Mange door: 1
Card number:40 000
store card record :100 000
Reader Input format:wiegand 26/ wiegand 34
communication: TCP/IP
Database: Access or SQL 2000,SQL2005,SQL 2010, default :Access
support OS: XP, WIN7,WIN8, WIN10
power:12V
*************************************************************************************************************************************************
