Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For

(No reviews yet) Write a Review
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
  • Raycus Max RA-HW1000 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For
$5,572.20

Description

1kw 1500w 2000w mini automatic portable handheld cnc fiber aluminum RAYLINE Laser Welding Laser Cleaning Laser Cutter

Name

RAYLINE LASER Handheld Fiber Laser Welding Machine

Model

RA-HW1000

RA-HW1500

RA-HW2000

Laser Power

1000W

1500W

2000W

Laser Wavelength

1064mm

1064mm

1064mm

Volage Regulating(Customized)

100-400VDC

100-400VDC

100-400VDC

Fiber Length

10m

10m

10m

Beam Diameter

0.2-1.5mm

0.2-1.5mm

0.2-1.5mm

Laser Welding Working Distance

100-300mm

100-300mm

100-300mm

Pulse Frequency (Adjustable)

1-100HZ

1-100HZ

1-100HZ

Aiming and Positioning ( rotate 360º)

 Red Linght

Red Light

Red Light

Shield Gas

One line(argon)

One line(argon)

One line(argon)

Cooling Method

Efficient cooling of water tank water circulation

Language

English, Russian, French, Korean, Portugal (Customized)

Application

Widely used in hardware industries such as cabinets, kitchens and bathrooms, staircase elevators, stainless steel homes, etc

1. The handheld fiber laser welding machine is mainly aimed at welding thin metal plates within 3mm, which makes up for the large thermal melting, easy deformation and post-processing troubles of traditional argon arc welding technology for thin plate welding.


2. The laser of the handheld fiber laser welding machine is in continuous light mode, the welding surface is smooth, the continuous light can be modulated through the self-developed system, and the frequency can be set from 5-200HZ.


3. The hand-held fiber laser welding machine has an integrated design with a built-in water cooler and 220V voltage access, which is more convenient to move and connect to electricity.


4. Both raw and skilled hands can quickly learn to operate, saving you expensive technical labor costs!


5. A variety of hand-held heads are available, and different hand-held welding heads can be selected for various needs such as external welding, internal welding, right angle welding, narrow edge welding, large spot welding and so on.


6. The handheld fiber laser welding machine can reduce the heat input to the minimum required amount, the metallographic change range of the heat-affected zone is small, and the deformation caused by heat conduction is also the lowest;


7. Workers are highly efficient, and it is not easy to be fatigued after long-term welding.
