Raycus Max 1000W 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For Sale
(No reviews yet)
Write a Review
Description
Raycus Max 1000W 1500W 2000W 3000W Portable Metal Handheld Fiber Lazer Welder Equipment Laser Welding Machine For Metal For Sale
CNC Metal Fiber Laser Welding Machine Description:
Technical Data
Item No. | ROBOTEC-RFL | |||||
Laser Power | 1000w | 1500w | 2000w | 1000w | 1500w | 2000w |
Laser Wavelength | 1064nm | 1080±5nm | ||||
Pulse Energy | 1.5mJ | 12mJ | 15mJ | 1.5-20mJ | ||
Fiber Length | 5m (Optioned) | 8-10m (15m Optioned) | ||||
Laser Cleaning Head Weight | ＜1kg | 3kg | ||||
Scanning Width | 10-80mm | |||||
Voltage | 220V, 50/60Hz | 380V, 50/60Hz | ||||
Cooling Method | Air-cooling | Water-cooling | ||||
Working Temperature | 0-40℃ | 10-40℃ | ||||
Fiber Laser Welding Performance Data
Laser power | 1000W | 1500W | 2000W | 3000W |
Conduction Type | Fiber laser | Fiber laser | Fiber laser | Fiber laser |
Laser Frequency | 50-5000HZ | 50-5000HZ | 50-5000HZ | 50-5000HZ |
Cooling Method | Water cooling | Water cooling | Water cooling | Water cooling |
Eectricity Requirements | single phase 220v ±10% 50/60Hz AC | single phase 220v ±10% 50/60Hz AC | three phase 380v ±10% 50/60Hz AC | three phase 380v ±10% 50/60Hz AC |
Welding Mode | Dot/Cricle/Line/8 mode | Dot/Cricle/Line/8 mode | Dot/Cricle/Line/8 mode | Dot/Cricle/Line/8 mode |
Welding penetration | 3mm | 4mm | 5mm | 6mm |
Total Power | 5.5kw | 7.7kw | 9.5kw | 14kw |
CNC Metal Laser Welding Machine Parts Pictures:
CNC Metal Laser Welding Machine Applications:
CNC Metal Laser Welding Machine Samples:
