Power Bank 20000mAh PD Type C Fast Charge Powerbank 10000mAh External Battery Portable Charger PoverBank for iPhone 12 11 Xiaomi
Description
Note:
1. Only 30000mAh Power Bank includes the strape and flash light.
2. Please charge-discharge powerbank 2-3 times to reach good capacity, it will be sorm of worming up for battery
22.5W Power Bank 10000mAh
22.5W Power Bank 20000mAh
22.5W Power Bank 30000mAh
Model : AS3WSFCP
Battery Capacity : 30000 mAh
Rated Capacity : 20000 mAh
Power : 22.5W Max
Type C input : 5V/3A, 9V/2A, 12V/1.5A ( PD18W Fast input )
Micro USB input: 5V/2.4A
USB-AI OutPut : 5V/4.5A, 4.5V/5A, 9V/2A, 12V/1.5A( 22.5W use alone )
USB-A2 OutPut : 5V/4.5A, 4.5V/5A, 9V/2A, 12V/1.5A(22.5W use alone )
Type C OutPut : 5V/3A, 9V/2.22A, 12V/1.67A ( PD20W use alone )
Fast charge agreement : QC3.0 QC2.0 PD3.0 PD2.0 FCP AFC SFCP
10W 5V2A Power Bank 10000 / 20000 mAh
Note:Please use up the power bank after receiving it, then recharge it, use it up, recharge it again, and cycle 3-5 times
Notice:
Please full charge the power bank first when you recieve it.
FAQ
Q: Why the battery capacity is 20000 mAh, but the rated capacity is only 13500 mAh? (Why it shows a capacity lower than 20000mAh when I test it?)
A: 1. Energy Conservation Law
The unit of measuring the power of the power bank is not only the "mAh", but also the "mWh"(voltage V * capacity I)
Since the standard lithium battery voltage of the power bank is 3.7V, the current charging voltage of mainstream mobile phones and computers, or other mobile devices is the standard 5V voltage of the USB interface. The mobile power supply must be boosted to 5V before charging the mobile phone.
For example:
The normal energy of a power bank with a capacity of 20000 mAh is 20000mAh * 3.7V = 74000mWh. After the booster circuit outputs 5V, the output capacity becomes 3.7V / 5V * 20000mAh = 14800mAh.
2. Energy Consumption During Charging
During the boosting process of the mobile power supply, due to the loss of the booster circuit itself, it cannot output 100% of all energy, and the conversion rate is related to the output current. Normally, when outputting 1A current, the conversion rate will be higher than when outputting 2A.
The conversion rate of the entire mobile power industry is basically in the range of 60% -70%.
