Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI

(No reviews yet) Write a Review
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
  • Partaker Fanless Mini Computer i7 8550U/7560U i5 8250U/7260U 2*DDR4 Msata+M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HDMI
$310.67 - $621.34

Description

Good News:


Send from China to EU/RU/UK by DPD or DHL, TAX Free, must choose seller's shipping method.





Processor has 4 options suitable for the same motherboard:


1. Kaby Lake R 14nm CPU Intel Core i5 8250U 4 cores 8 threads 1.6Ghz Max to 3.4Ghz 6MB cache TDP 15W Intel UHD Graphic 620.(Sliver Color)

2. Kaby Lake R 14nm CPU Intel Core i7 8550U 4 cores 8 threads 1.8Ghz Max to 4.0Ghz 8MB cache TDP 15W Intel UHD Graphic 620.(Black Color)

3. Kaby Lake 14nm CPU Intel Core i5 7260U 2 cores 4 threads 2.2Ghz Max to 3.4Ghz 4MB cache TDP 15W Intel Iris Plus Graphic 640.(SliverColor)

4. Kaby Lake 14nm CPU Intel Core i7 7560U 2 cores 4 threads 2.4Ghz Max to 3.8Ghz 4MB cache TDP 28W Intel Iris Plus Graphic 640.(Black Color)






How to select Configuration?

For example:
1. You click " No Ram No SSD WiFi" from Color and "i7 8550U 8650U DDR4" from Bundle, we will ship the mini pc with processor i7 8550U/8650U but no ram no storage included and No O/S to you.
2. You click "8G Ram 128GB SSD WiFi" from Color and "i5 8250U 8350U DDR4" from Bundle, we will ship the mini pc with processor i5 8250U 8350U 8GB Ram 128GB SSD and Windows preinstalled to you.



Kindly be noted:


1, The Processor is Intel i7-8550U/i7 8559U/i7 8565U
CPU: 4 Cores, 8 Threads; Base Frequency: 1.8GHz, Max. Turbo Frequency: 4.0GHz, 8MB Smart Cache,
integrated Intel UHD Graphics 620: 4K:4096x2304@24Hz, Graphics Base Frequency: 300MHz; Graphics Max Dynamic Frequency: 1.15GHz.


2, The Operating System is Windows 10 Pro;

Installing a new system from USB drive, continuously press the button of "F11"

Entering the interface of BIOS, continuously press the button of "Delete"


3, There are 2 types of DP cables available: “Active” and “Passive”.
The DP port of the computer works with “Active” type DP cable, if yours is "Passive", it won't display.

Front-Panel:
1xPower switch button 1xLED Power Indicator
4 x USB 2.0

Back-Panel:
1*12V DC input 1*HD port 1*DP port
2 * Intel 82574L Giga LAN Port. 4*USB 3.0 ports
2 * Audio In/output 2*Wi-Fi Connectors for Antennas.

Motherboard:
Chipset: Intel SOC chipset with L3 Cache 8MB
Memory Slots: 2 SO-DDR4 SDRAM memory slots
Sound card: ALC892 chip, providing 6-channel sound
Drive Interface: 1* mSATA 3.0, 1*NGFF with 2280 M.2 Size, 1*SATA 3.0,
1*PCI-e for half size wireless network card: 300M 2.4/5Ghz dual band Wi-Fi built-in module, dual external antennas enhanced signal 802.11.b/g/n.

Power supply:Input: 100-240V; Output: 12V, 5A.



Barebone system no ram no storage, please use DDR4-2133/2400 260pin laptop original brand SODIMM Ram, Msata SSD and M.2 NVMe/NGFF/PCIE SSD, don't support DDR3/L Ram installation.


IF buyer purchase barebone system no ram, seller is irresponsible and makes no compensation for your own ram if it is incompatible on this pc.



i5 8250U/i5 8350 model: 4*USB3.0, 4*USB2.0, 1*HDMI, 1*VGA, 1*Lan



i7 8550U/i7 8565U/i7 10510U model: 4*USB3.0, 4*USB2.0, 1*HDMI, 1*DP, 1*Lan


i5 7260U model: 4*USB3.0, 2*USB2.0, 1*HDMI, 1*DP, 2*Lan





Free Operating System: Default installed our activated OEM cracked version(not genuine, works good)Windows English for free, other languages can be selected among: Russian,Spanish,Portuguese,French,German,Arabic,Italian,Japanese,Turkish,Greek etc.  Please inform us which language you want to install, defalut is english version. Other systems we can install free are like Linux, XBMC(Kodi), Ubuntu, Openelec etc if you need. Seller is irresponsible and makes no compensation for cracked system.




Key Features

CPU

 Intel Core i7 8550U 1.8GHz Max 4.0GHz (Turbo boost Technology) 4 Cores 8 threads

RAM

Support 2G/4G/8G/16G/32G (2*16G) DDR4-2133MHz

Storage

Support mSATA SSD and 2.5 inch laptop HDD/SSD; can install maximum 1 HDD (2.5 inch) +1 SSD (mSATA 3.0) together

Graphics

Intel graphics HD 620,support ultra HD 4K resolution

I/O

Mic; Speaker; 4* USB 3.0 port; 4* USB 2.0 port; 1* RJ45 Gigabit LAN Port; 1* DP; 1* HDMI; 1* DC12V In;


Operating System

Windows 7/8/10, Linux Compatible, suggest OpenELEC for less than 16GB SSD, Win7 or Win8 for up to 32GB storage

Language

Multi Language

Feature

Fanless

USB port

4* USB 3.0+4* USB 2.0

Wireless

300MB Wifi with 2 Antennas

HD Output

1* HDMI port, support 4k output; 1* DP port, support HDMI+DP dual display

LAN port

1* Gigabit RJ45 port speed up to 1Gbps

Power and Environment

Input

DC100-240V AC/50-60Hz

Output

DC 12V~3A/5A

Operating Temperature

0/70 Centigrade (32F~140F)

Storage Temperature

-20/+85 Centigrade

Relative Humidity

0%~90% (non-condensing)

Energy-saving

Support Energy-saving technology, Speedstep

64 bit computing

Support 64 bit computing

Virtualization

Support Virtualization technology

Hyper-threading

Support Hyper-Threading

Consumption

15W~28W

Physical Properties

Material

Brushed Aluminum Alloy

Weight

NW:2.0Kg   GW:2.7Kg

Package Content

1* Mini PC; 1* power adapter; 2* Antennas

Warranty

30 days free defective replacement and 3 years free repair


Key Features

CPU

Onboard Intel Core i5 8250U 1.6GHz up to 3.4GHz (Turbo boost Technology) Quad Core 8 thread 6M cache

RAM

Support  2*DDR4-2133/2400 laptop ram Maximum 32GB RAM

Storage

Support 1pcs mSATA SSD+1pcs M.2(NVMe) SSD+1pcs 2.5 inch laptop HDD/SSD installation together

Graphics

Intel graphics UHD 620,support ultra HD 4K resolution

I/O

Mic; Speaker; 4* USB 3.0 port; 2 or 4* USB 2.0 port; 1* RJ45 Gigabit LAN Port; 1* VGA; 1* HDMI; 1* DC12V In;

Operating System

Windows10, Linux Compatible, OpenELEC

Language

Multi Language

Feature

Fanless system design, without noise

USB port

4*USB 3.0+2 or 4*USB 2.0

Wireless

300MB Wifi with 2 Antennas

HD Output

1* HDMI port, 1* VGA port, support HDMI+VGA dual display

LAN port

1* Gigabit RJ45 port speed up to 1Gbps

Power and Environment

Input

DC100-240V AC/50-60Hz

Output

DC 12V~3A/5A

Operating Temperature

0/70 Centigrade (32F~140F)

Storage Temperature

-20/+85 Centigrade

Relative Humidity

0%~90% (non-condensing)

Energy-saving

Support Energy-saving technology, Speedstep

64 bit computing

Support 64 bit computing

Virtualization

Support Virtualization technology

Hyper-threading

Support Hyper-Threading

Consumption

15W~28W

Physical Properties

Material

Brushed Aluminum Alloy

Weight

NW:2.0Kg   GW:2.5Kg

Package Content

1* Mini PC; 1* power adapter; 2* Antennas

Warranty

30 days free defective replacement and 3 years free repair



Key Features

CPU

Onboard Intel Core i7 7560U 2.5GHz Max 4.0GHz (Turbo boost Technology) Dual Core 4 thread, Black color

Onboard Intel Core i5 7260U 2.2GHz Max 3.4GHz (Turbo boost Technology) Dual Core 4 thread,Silver color

RAM

DDR4-2133/2400/2666MHz support Maximum 32GB RAM

Storage

Support mSATA SSD and 2.5 inch laptop HDD/SSD; can install maximum 1 HDD (2.5 inch) +1 SSD (mSATA 3.0) together

Graphics

Intel Iris Plus Graphics 640 ,support ultra HD 4K resolution

I/O

Mic; Speaker; 4* USB 3.0 port; 4* USB 2.0 port; 2* RJ45 Gigabit LAN Port; 1* DP; 1* HDMI; 1* DC12V In;


Operating System

Windows 7/8/10, Linux Compatible, suggest OpenELEC for less than 16GB SSD, Win7 or Win8 for up to 32GB storage

Language

Multi Language

Feature

Fanless

USB port

4* USB 3.0+4* USB 2.0

Wireless

300MB Wifi with 2 Antennas

HD Output

1* HDMI port, support 4k output; 1* DP port, support HDMI+DP dual display

LAN port

2* Gigabit RJ45 port speed up to 1Gbps

Power and Environment

Input

DC100-240V AC/50-60Hz

Output

DC 12V~3A/5A

Operating Temperature

0/70 Centigrade (32F~140F)

Storage Temperature

-20/+85 Centigrade

Relative Humidity

0%~90% (non-condensing)

Energy-saving

Support Energy-saving technology, Speedstep

64 bit computing

Support 64 bit computing

Virtualization

Support Virtualization technology

Hyper-threading

Support Hyper-Threading

Consumption

15W~28W

Physical Properties

Material

Brushed Aluminum Alloy

Weight

NW:1.65Kg GW:2.7Kg

Package Content

1* Mini PC; 1* power adapter; 2* Antennas

Warranty

30 days free defective replacement and 3 years free repair



Please noted CPU i5 7260U/i7 7560U all cancelled SD reader card, now the new batch wihout SD reader card.
