Multifunctional OTDR FTTX VFL OPM SLS optical fiber maintenance professional equipment Optical time domain reflectometer
Description
Product Information:
2. Optical Power Meter : -70~+10dbm(default) or -50~+26dbm
3. Visual Fault Locator : >=10mw
4. Optical Light Source : 1310/1550nm ,>-5dBm
We will configure the power connectors according to your country of delivery.
Smart handy OTDR is portable fiber fault locator, it is quickly to detect fault location and type of optical fiber using OTDR element and stronger software analysis tool.
Features:
1. Lightweight, portable, cost-effective
2. One Key Operation, Legible Test Data
3. Integrated with Visual Fault Locator system, it is easily to detect fault location of dead Zone
4. Use the rubber Key, good dustproof, waterproof, quakeproof ability, suitable for field maintenance work
5. Use big capacity battery, long working time, suitable for long time field working
6. Suitable for engineer construction and maintenance fault location of FTTx and access network
Specifications
1. OTDR
| Wavelength | 1310/1550nm |
| Dynamic Range | 22/20dB |
| Measure distances | 0-60km |
| Fiber type | SM |
| Type of Fiber | 9/125um Single-mode optical fiber |
| Type of Connectors | FC/PC/; SC/PC |
| Peak Value of laser | >=30mW |
| UOM of Measurement | Meter,Feet,Mile |
| Dead Zone of Reflection Event | 2m |
| Dead Zone of attenuation Event | 12m |
| Accuracy Distance (Reflection Event) | About +_(1m+2 *10(-4)* distance) |
| Number of test records saved | 100 |
| Power Supply | 8.4V Li-ion Battery 4400mAH |
| Battery working time | >=5,000 times of measurements |
| Temperature | Operate :-5~50 ,Store:-10~60 |
| Humidity | 0~85%(Non-condensing) |
| Weight(g) | 300 |
2. Visual Fault Locator
| Wavelength : | 650nm |
| VFL Output Power | >=10mW |
| Mode | CW,1Hz,2Hz |
| Fiber type | SM/MM |
3.Optical Power Meter
| Measurement range dBm | -70～+10 dBm | -50～+26 dBm |
| Wavelength range(nm) | 800～1650 | |
| Calibrated wavelength | 850nm,1300nm,1310nm,1490nm,1550nm,1625nm(other wavelength will be on request) | |
| Detector | InGaAs | |
| Accuracy | <±3% (-10dBm,22℃) | |
| Resolution | Linearity:0.1%,Non-linearity:0.01dBm | |
| connector | Changeable FC/PC SC/PC,( ST as Optional) | |
4.Optical Light Source
| Emitter | FP-LD |
| wavelength (nm) | 1310/1550nm |
| Connector | FC/PC(SC/ST as optional) |
| Output power | ≥-5dBm |
| Output stability(dBm) | ±0.04@20℃@15min |
| Modulation | CW/270Hz/1KHz/2KHz |
| Fiber type | SM |
