Package list

The package includes :1PCS motherboard + 1PCS processor + 2PCS memory.
Motherboard :E5 MR9A PRO MAX
CPU: Intel Xeon E5-2690 V4
Memory :2X16G=32GB DDR4 2133MHz RAM(Machinists brand)
Gifts :SATA cable, I/O backplane, instruction manual
The motherboard is brand new with a one year warranty
The cpu is used and has a 2 year warranty. Don't buy it if you mind

CPU

Processor Series: Intel Xeon
Model number: E5 2690 V4
Processor Speed: 2.6 GHz
Processor Socket: 2011-3
stepping: SR2N2
The number of CPU cores: 14
The number of threads: 28
L3 cache size (MB): 35MB
Wattage: 135Watt
Cpu will be final double tested before shipping.
For more information about CPU compatibility, consult online customer service

Motherboard parameters:

Brand: MACHINIST
Model:E5 MR9A PRO MAX
Chipset: Q87
CPU socket: LGA2011-3( v3，v4）
M.2 interface：NVME M.2 SATA M.2 WIFI M.2
Structure:ATX
Memory slot: 4*DDR4
Memory channel:Four-channel
Maximum memory capacity: 4x32=128GB DDR4
Technology: Quad-channel DDR4 2133/2400/2666/3000/3200MHz
Memory type supported:supports DDR4 Desktops and servers memory. (Please use Samsung, Kingston, SanDisk, Micron, Hynix international brands. Not compatible with other brands)
SATA ports: 6 (2 SATA2.0, 4 SATA3.0)
power socket: 8PIN +24PIN power socket
USB port: 2*USB 3.0; 6*USB 2.0
Audio: 1 (Mic-in, Line-out, Line-in)
Ethernet: 1 Realtek Gigabit LAN
PS/2: 1 KB interface and 1 MS interface
USB 2.0: 2 (one FUSB can transfer two USB 2.0 ports);
USB 3.0: 2 (one FUSB can transfer two USB 3.0 ports);
Serial port: 1*2x5Pin pin
FAN: 4 (1*CFAN+3*SFAN)
PCIe: 3*PCIe x16: 1*PCIe x4: 1*PCIe x1)
JAudio: 1 2x5Pin pin
Switch and restart: 2 independent buttons
JLPC: 1 2x5Pin pin
Diagnostic card: 1
Motherboard :300mm*215mm
Motherboard weight (including packaging): about 1.45kg

Note:

1. Regarding the customs declaration: we will do our best to help buyers to reduce the value of the package: (20-30$) but there is no guarantee that it can be completely avoided! If the buyer makes the actual value modification declaration and generates the customs duties, they need to charge it by themselves! If you are unfortunately taxed, please actively cooperate with customs clearance, otherwise the package will be destroyed or returned by itself! Don't make a wish if you mind
2: The color of the bottom notch plate may vary from batch to batch, but it will not affect the use of the product. Products are continually optimized and updated.
3: Due to manual measurement, please allow 1-3mm difference.
4: Due to different monitors and different light, the pictures may not show the actual color of the goods. Thank you for your understanding.
5: This platform needs a powerful power supply. Make sure your power supply is enough to support the plan (at least 600w type power supply)
6. The motherboard does not come with a coms battery when it leaves the factory. After receiving the motherboard, the battery needs to be installed and then discharged. Battery Model (CR2032 Voltage: 3v)
7. If you have other requirements for the processor model and memory capacity, you can contact online customer service and we will customize it for you (besides, our store provides accessories like memory, nvme m.2 , fans for purchase)
8. All motherboards can provide BIOS files and drivers, please contact customer service for files

For Customs duties problem , pls make sure you can solve the customs clearance problems by yourself, if you can't solve it, we don't advise you to buy goods in our store. We are not responsible for customs duties. Thanks for your kindly understanding.
