Brand

LR-LINK

Model

LREC9902BF-2QSFP+

Controller

Intel XL710BM2

Transmission Rate Per Port

40 Gigabit

Network Standard Physical Layer Interfaces

40GBASE-SR4/LR4

40GbE QSFP+ AOC/DAC

Jumbo Frame Support

Up to 9.5 KB

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

Network Virtualization

VXLAN, NVGRE, Geneve, Network Service Headers (NSH), VEPA, VEB

LED Indicators

40Gbps: Yellow LINK on; Blue ACT blink

Power Supply

PCI Express +12V±8% / +3.3V±9%

Operating System Support

Windows Server 2008 R2 / 2012 / 2012 R2 / 2016 R2

Windows 7 / 8 / 8.1 / 10

FreeBSD 9 / 10 or later

Linux Stable Kernel version 2.6.x / 3.x / 4.x or later

VMware ESX/ESXi 5.x/6.x or later
