Model Type

STBL-30.4

STBL-39.3

STBL-40.3

WorkHeightMaximum

32.4 m

41.3 m

42.3m

PlatformHeightMaximum

30.4m

39.3 m

40.3m

Horizontal reach maximum

21.4m

21.5 m

21.6m

Liftcapacity(restricted)

480 kg

480 kg

360 kg

Liftcapacity(non-restricted)

340 kg

340 kg

230 kg

Length(stowed)  Ⓓ

13 m

13.65 m

11m

Width(axle retracted/extended)  Ⓔ

2.5m / 3.43m

2.49 m

2.49m

Height(stowed) Ⓒ

3.08m

3.9 m

3.17m

Wheelbase Ⓕ

3.66m

3.96 m

3.96 m

Groundclearance  Ⓖ

0.43m

0.43 m

0.43 m

PlatformmeasurementⒷ*Ⓐ

2.44*0.91m

0.91*0.76 m

2.44x0.91

Turning radius( inside,axle retracted)

4.14 m

3.13 m

4.13m

Turningradius (inside,axle extended)

2.74 m

3.13 m

3.13m

Turning radius( outside,axle retracted)

6.56 m

5.43 m

7.02m

Turningradius(outside,axle extended)

5.85 m

6.75 m

6.5m

Travelspeed(stowed)

4.4 km/h

Travelspeed(raised)

1.1km/h

Grade ability

40%

Solidtire

385/65D-24

Turntableswing

360° Continuous

Platformleveling

Automaticleveling

Platformrotation

±80°

Fuel tankcapacity

150L

Drive & Steering mode

4x4x4

Engine

America Cummins B3.3 80 HP (60kw),

Lovol 1004-4 78 hp (58kw),Perkins 400 76 hp (56kw)

Totalweight

18500kg

20820kg

21000kh

Controlvoltage

12V DC Proportional

24V DC Proportional

24V DC Proportional
