Wireless WiFi Carplay Android Auto 10.36 Inch 4 Split Screen Truck Bus Dash Cam DVR Recorder Monitor with 4PCS 1080P Mini Camera

Feature :

* Wireless Apple Carplay and Airplay, you don't need to use a data cable. You just need to turn on Bluetooth and WiFi to connect, and Carplay will automatically connect next time. You can use voice control Carplay to play music, navigate, view text messages, etc.
* Wireless Android Auto and Android Cast, you don't need to use a data cable to connect. You just need to turn on Bluetooth and WiFi to use Android auto. You can use Android auto for voice control, music, navigation, etc.
* Support MirrorLink, mobile screen casting function.(only Android phones with Android auto function can be used to operate this item)
* Support Wireless WiFi APP. You can play back Recording videos and pictures through the APP.
* 10.36 Inch IPS touch Screen. High-definition 500CD/M2, AHD1920x1080P video inputs. 4 Channel Screen split display.
* Support 9V-36V wide Voltage, really an ideal system for car surveillance, suitable for small trucks, buses, pickip trucks, work cars, large truck, etc.
* Install four HD cameras in front, left, right and rear side of the vehicle, separately connect them to the monitor. You will enjoy real-time driving monitor, driving assistance, parking monitor anytime & anywhere.
* Support AHD 1080P camera, Clearer and advanced bright color separation, signal filtering, 3D noise reduction technology, higher image clarity and better image reproduction.
* Support DVR for loop recording, Maximum 258G TF card.
* Support FM Stereo Radio Audio and Bluetooth Audio, can be connected to the original car audio, improve the sound quality.
* Support Bluetooth. MirrorLink can play video, music.
* Support camera image screen mirroring function.
* Support reversing line calibration and switch (screen comes with reversing Line).
* Support screen saver function, automatically turn off the screen , drive safer at night .
* Support voice control, for example, open the screen, close the screen, display the main screen, display a certain camera screen.
* Support display time and date, can set the license plate, can adjust the brightness and volume.

Apple CarPlay

Click the 'Apple CarPlay' button, then select the 'Apple CarPlay' option, and first turn on the phone's WiFi and Bluetooth, as shown in the above figure. Bluetooth will automatically turn on, named T59CARPLAY-XXX. Once Bluetooth is successfully connected, you can connect to Apple CarPlay. (When the machine is powered on, it will attempt to automatically connect to the last connected phone)

Andorid Auto

Click the [Android Auto] button, and then select the [Android Auto] option, first turn on the phone's WiFi and Bluetooth, as shown in the picture above. Bluetooth will be turned on automatically and the name will be T59CARPLAY-XXX. Once the Bluetooth is successfully connected, you can connect to Android Auto. (When the machine is powered on, it will try to automatically connect to the last connected phone)

Apple Airplay

Airplay can transmit video, audio and pictures from iPhone device to car equipment. The carrier of transmission is WiFi, which is fundamentally different from Bluetooth wireless.

Android Cast

It can realize the mirror projection of the mobile phone and the car machine.
You need to scan the code with your mobile phone to download, install and run the "TcLink" application.

WiFi Video

After open the APP, and follow the APP prompts to connect to the WiFi of the machine. WiFi name: RTSP-XXXXXX, password as shown on the machine.

Premium AM/FM Radio

Driving in rainy conditions or on the highway won't be an issue, you can listen to real-time radio, weather forecasts, news so that your driving is no longer boring. Adjust the Car stereo's FM and the car's FM to the same frequency, it can connect the car speaker.

DVR Display Screen Menu Comments

Use various monitor functions more conveniently and quickly

Loop Recording

Parking video recording and playback, it will record the parking video in 24/7 mode when you are not inside of the car. The storage support up to 256GB. Automatically overwrite the previous recordings with new files when the memory card is full.
Adopt Time-lapse video recording technology, save more space and no need to format the memory card often. (Note: Time-lapse video recording is only available during parking period, the monitor will always support normal video recording during driving.)

11 Language Settings

*11 Kinds menu language : English/Russian/Spanish/French/German/Japanese/Korean/Italian/Polish/Chinese

IPS Screen

Restore true colors from all angles

Split Screen Mode

After selecting the Split screen mode, half of the screen displays the Apple CarPlay/Andorid Auto interface and half of the screen displays the front road camera view when using the Apple CarPlay/Andorid Auto mode with cell phone connectivity.
(This feature is only available in Apple CarPlay/Andorid Auto mode)

Two Bracket Installations

Car ceiling mounting bracket Need to choose to buy

For TC1364 Monitor

GreenYi AHD1080P Camera

With AHD 1080P Camera lens, the quality of shooting video is delicate and clear even in low light conditions at night.
Default 1pcs 15 meters extending cable for rear view, 3pcs 5 meters extending cable for front, left and right view. Support to customize the cable as you need.
Support waterproof IP68.
GreenYi store has many types of AHD cameras, ha have different lengths of custom cables, welcome to buy.

For 899 Camera

For 879 Camera

Wiring Diagram :

Install four AHD cameras on the front, left, right and rear side of the vehicle, respectively connected to the monitor. You will enjoy real-time driving monitoring, parking monitoring, and driving records anytime, anywhere

4-Pin Aviation Cable

We use the wire which update from standard 4mm to be 4.5mm, longer life lt will be. Inside of the wire much more copper wire covered with special tinfoil wrap up. Avoid the loose of the signal. Great signal will be no matter wherever you are in. the cable is 5M / 10M /15M / 20M Optional .

Package content:

1 x 10.36 Inch BSD DVR Monitor
4 x AHD 1080P Front Rear Camera
3 x 5m Video Cable
1 x 15m Video Cable ( 10M/20M Optional )
1 x Desktop Bracket and screw
1x Cigarette lighter power cord
1 x Power Cable
1 x Car ceiling mounting bracket (optional )
1 x TF Card(Optional)
