Gigabit Fiber Optical Media Converter 10/100/1000Mbps Dual Fiber SC Port RJ45 to 1000Base-LX up to 20km

(No reviews yet) Write a Review

SKU:
UPC:
MPN:

$26.36

Current Stock:

Quantity:

Description

Description

Overview:
Bi-directional 100/1000M adaptive Ethernet fiber transceiver with the latest chips, high quality dual-fiber bi-directional optical transceiver module (brand new manufacture), stable performance and high quality. It is suitable for data transmission in telecom, broadcasting, broadband fiber optic networks and network environments that require improved performance and high reliability.

The Transceiver converts 1000BASE-SX/LX/LH/EX/ZX fiber to 10/100/1000Base-T copper media or vice versa. It is designed for use with transmitting data up to 20 kilometers. What's more, the SFP to Ethernet Converter can work as a standalone device (no chassis required) or with EWIND’s 19” system chassis.

Features:
1. One RJ45 port and two single-fiber SC optical ports for optical signal conversion between 100/1000base TX twisted pair (Ethernet) and 1000base FX (fiber).
Optical signal conversion between Ethernet (Ethernet) and 1000base FX (fiber);
2. Compared to dual-fiber data transmission, core fiber can only be used in one way to complete the signal transmission.
doubling of the modulus;
3. complies with IEEE802.3 10Base-T and IEEE802.3u 100Base-TX, 100Base-FX standards;
4. Adaptive capacity of 100M/1000M;
5. Ethernet interface with adaptive direct/crossover network connection;
6. support full/half duplex mode;
7. built-in lightning protection circuit, which can greatly reduce the loss caused by lightning induction;
8. six LED indicators: Power, TX100, TX Link/Act, FX100, FX Link/Act, FDX/Col; easy to monitor
the status of the transceiver and determine the cause of failure;
9. operating temperature: 0 to 50 degrees;
10. storage temperature: -40 to 70 degrees;

Descripation:

1.Works at 10/100/1000Mbps in Full-Duplex mode for both TX port and FX port;

2.Supports Auto MDI/MDIX for TX port;

3.Provides switch con-gyration of Force /Auto transfer mode for FX port;

4.Extends -fiber distance up to 20km for single-mode fiber;

5.Easy-to-view LED indicators provide status to monitor network activity easily;

6.The Distance support to 20KM.

7.1x RJ45 port and 1x fiber SC port

8.Connector：Dual Fiber SC port

Data Rate：1000Mbps

Duplex Mode：Full duplex

Fiber：SM 9/125um
