Eglobal Fanless Mini pc i7 8550U 7560U 7260U gaming pc 2DDR4 Msata M.2 SSD Micro PC Win10 Pro Barebone HTPC Nuc VGA HD
Description
Buy with confidence! 3 Years long warranty for fanless system!
1)-Advanced newest intel processor, assure powerful performance for gaming, office, drawing;
2)- 2*DDR4 RAM slots 2xfaster than 1 ram slot, DDR4 2xfaster than DDR3;
3)- Noiseless: Fanless system, all aluminum passive heatsink, low consumption, 0.00dB noise;
4)- Triple-Storage: support 1*Msata SSD+1*M.2(22x80) SSD+1*2.5'' SATA HD;
5)- Slim volume: Can stand on desk by free bracket we supply， mount back of monitor by VESA bracket;
| General | |
| CPU | 1.8th Gen 14nm CPU Intel Core i7 8550U 4 cores 8 threads 1.8GHz up to 4.0GHz 8MB cache TDP 15W Intel UHD Graphics 620. (probably send i7 8565U 8650U by stock) 2. 8th Gen 14nm CPU Intel Core i5 8250U 4 cores 8 threads 1.6GHz up to 3.4GHz 6MB cache TDP 15W Intel UHD Graphics 620. (Probably send i5 8265U 8350U by stock)
3. 7th Gen 14nm CPU Intel Core i7 7560U 2 cores 4 threads 2.4GHz up to 3.8GHz 4MB cache TDP 15W Intel Iris Plus Graphics 640. (Sorry it is out of stock)
4. 7th Gen 14nm CPU Intel Core i5 7260U 2 cores 4 threads 2.2GHz up to 3.4GHz 4MB cache TDP 15W Intel Iris Plus Graphics 640. (Probably send i5 7267U by stock) |
| Core (FSB) | 100MHz |
| CPU Technique | 14nm |
| L3 Cache | 6MB SmartCache, CPU Integrated |
| BOIS | AMI BIOS, ACPI supported Support calls on function automatically Support Wake-On-LAN |
| Chipset | Intel KABYLAKE |
| Memory | 2* SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB Dual Channel, DDR4-2400, LPDDR3-2133 |
| Storage | Support 1*mSATA SSD+1*M.2(NVMe/SATA) SSD+1*2.5'' SATA HDD/SSD installation together |
| Operating System | Win 10/Linux |
| Audio | ALC897 chip, 7.1 channel sound Intel Lynx Point-LP HDA |
| Network | Onboard Realtek RTL8168E PCI-E Gigabit Ethernet NIC Onboard RTL8111DL10/100Mbps/1000Mbps BaseT LAN |
| Video | Intel UHD Graphics 620 Intel® Iris® Plus Graphics 640
|
| I/O port | |
| front panel ports | 1* Power indicator and switch, 4*USB2.0 |
| Backside ports | 2*WiFi antennas, 1*MIC, 1*SPK, 4*USB3.0, 1*LAN, 1*VGA, 1*HD, 1*DC 12V |
| Internal ports | 1*M-SATA3.0 port, support 6Gb/s 1*M.2 SSD port, support 6Gb/s 2*SATA3.0 port, support 6Gb/s 1*mini-PCIE port(WIFI&Bluetooth) |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 12V~19V/5A |
| Operating Temperature | 0/70 Centigrade(32F~140F) |
| Storage Temperature | -20/+85 Centigrade |
| Relative Humidity | 0%~90% (non-condensing) |
| Energy-saving | Support Energy-saving technology, Speedstep |
| 64 bit computing | Support 64 bit computing |
| Virtualization | Intel VT-x |
| Hyper-threading | Support Hyper-Threading |
| Product Dimension & Details | |
| Size | 208*180*45MM |
| Weight | 3.0KG |
| Consumption | 15W |
| Shell | Silver color aluminum alloy |
| Package Content | Mini PC device, power adapter, a stand holder, a VESA mount(optional), dual WiFi antennas(optional), a HD cable( as a gift), a Screw Bag, Warranty Card |
Systerm Service
1.We can pre-installed well the OEM Windows OS for u before shipment, if u order the Mini PC bundle with RAM and SSD, please kindly leave us message which os u want to install. English version is for free, other languages can be selected amount Russian, Spanish, Portuguese, French, German, Arabic, Italian, Japanese, Turkish, Greek etc, Please inform us which language u want to install. Other systems we can install for free are like Linux, XBMC(Kodi), Ubuntu, Openelec etc if u need, seller is not responsible and make no compensation for OEM system.
2.Accessories as Ram, SSD, HDD, we use famous brand: samsung, micron, SanDisk, toshiba, hynix, crucial, liteon, kingston, phison etc , What brand we use depends on our test and our stock. What brand we use depends on our test and our stock. Generally we use Msata SSD installed on Mpcie port and leave the SATA port blank for you to install 2.5'' SSD/HDD. The bundles is not including the HDD, if u need HDD, please talk with us online to discuss, we will quote u best seperately price for it.
Tips:
DO NOT buy "no ram no storage" bundle if you are not Computer Expert, PC had best to use Samsung, SKhynix, Micron etc original brand accessories, We DO NOT compensate for buyer's own ram and hard drive.
1.Barebone mini PC (No RAM No storage) package DO NOT include WiFi, if you need, please pay extra US $7 at below link.
2.USB Infrared remote (can turn power off but not on) add extra cost US$14.
3. Bluetooth4.0 USB Dongle add extra cost US$5.
4. External USB DVD-ROM add extra cost $18, External USB Bluray DVD-ROM add extra cost $45.
5. USB 2.4GHz Air Keyboard& Mouse, add extra cost $20.
6. Genuine OEM windows license sticker add extra cost 35$.
7. 500GB 2.5'' HDD add extra 50$, 1TB 2.5'' HDD add extra 65$, 2TB 2.5'' HDD add extra 100$.
Upgrading link:
ht(how many dollars to upgrade, pay how many pieces, US$1=1pcs, For example upgrade USB IR remote, pay 14pcs for US$14, remember to leave message noting which one you upgrade for...)
i5 8250U model: 4*USB3.0, 4*USB2.0, 1*HDMI, 1*VGA, 1*Lan
Shipping Notice:
Normally we will provide free shipping by DHL, but we will also send by the other carriers for free shipping in different cases, they are UPS/EMS/Fedex etc.
Case 1: Your shipping area is remote location for DHL. You could find out if your area is remote area or not on DHL the website: raslist.dhl.com/jsp/first.jsp
Case 2: DHL is not allowed to use in your area. Like Russia, Brazil, Argentina.
Case 3: Good news for customers from Russia Belarus Ukraine Brazil etc countries, we choose eEMS(EMS upraded version) to ship parcel by default, safe, fast, with better ability of customs clearance. Delivery within about 5-10 working days by eEMS.
Except all of 3 cases, If your address is remote area for us , you should add extra shipping fees for DHL/ UPS/EMS/Fedex etc, otherwise we will choose post mail shipping for free.
Free Shipping Details:
1.The following countries by DHL free shipping:
Israel, America, Belgium, the Netherlands, Luxembourg, Italy, Germany, Britain, France, SAN marino, Austria, Denmark, Finland, Portugal, Sweden, Switzerland, Spain, Greece, Norway, Bulgaria, Cyprus, Estonia, Latvia, Lithuania, Malta, Slovakia, Slovenia, The Czech republic, Hungary, Poland, Romania etc.
2. Free shipping e-EMS or Fedex to Japan and South Korea.
3. Free shipping Post Service to other countries.
About customs, We are not responsible for buyer's customs any storage costs, brokerage, taxes or VAT etc fees. But we try our best to help buyer lower or avoid customs duties, if u need to write a real invoice value, please donot forget to leave us message, otherwise we will write about 100USD per unit.
