Note：

This product does not come with a power supply. The product supports three types of power supply: 12V/1A power supply, 5V portable charger (power bank) and battery. You can choose the suitable power supply according to your needs.

Features:

2.5dB ultra-low noise
5V to 16V operating input range
Working with certified IEEE 802.11b/g/n Wireless LAN devices
Simply plug and play, no software is required
50X the power, improving the link quality and coverage of certified WLAN devices

Specifications:

2.4GHz Channel Parameters:
1.Frequency Range :2400-2500MHz
2.Operating Voltage :5-16V
3.Receiving Gain :18dB±1
4.Transmission Gain: 18dB±1
5.Max Output Power(P1dB) :36dBm(4W)
6.Input Trigger Power :Min:3dBm Max:23dBm
7.EVM :3%@28dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz
8.Noise Figure :＜2.5dB
9.Current Supply :580mA@Pout 28dBm 12V
10.TX/RX Switch Time Delay :＜1 us
11.LED Indicator :Transmitter: Green; Receiver: red
12.Operating Temperature :-30℃～+70℃
13.Storage Temperature :-40℃～+150℃
14.Operating Humidity :Up to 95% rel. humidity
15.RF Connector :Input: SMA-K; Output: RP-SMA-K
16.Power Socket :2.5*0.7mm DC
17.Shell Size :65*61*12(mm)
18.Shell Material :Aluminum
19.Net Weight :0.12Kg

Shipping and Returns:

Shipping is available from China, Russia and Spain

Warranty:

Products ordered from China come with a 75-day money-back guarantee.
