EDUP 20W/10W Bidirectional WiFi Booster Wireless WiFi Signal Extender Drone Signal Amplifier 5.8 Ghz Power UAV Range Extender
Description
Features:
Applications FPV Signal Extender And Drone Signal Extender
60X the power, improving the link quality and coverage of certified devices
2.5dB ultra-low noise
Aluminum-alloy case by CNC, anti-interference; Designed for FPV Drones, UAV, RC equipment
Simply plug and play, no software is required.
Specifications:
Booster Model: EP-AB043
Frequency Range: 5150-5850MHz
Operating Voltage: 12-24V
Receiving Gain : 18dB ±1
Transmission Gain : 18dB ±1
Max Output Power(P1dB):43dBm(20W)
Input Trigger Power: Min:3dBm Max:22dBm
EVM:3%@34dBm 802.11g 54Mbps
OFDM 64QAM BW 20MHz
Noise Figure:＜2.5dB
Current Supply：2.6A@Pout 37dBm 12V
TX/RX Switch Time Delay:＜1 us
LED State: Transmitter :Red; Receiver:Green
Operating Temperature: -30℃～70℃
Storage Temperature: -40℃～+150℃
Operating Humidity: ＜95%RH
RF Connector: Input: SMA-K; Output: SMA-K
Power Socket: 5.5*2.1mm
Shell Material: Aluminum
Shell Size:104*60*17mm
Net Weight: 0.27Kg
Shipping and Returns:
Shipping is available from China, Russia and Spain.
Warranty:
Products ordered from China come with a 75-day money-back guarantee.
