Aqara Smart Wall Switch E1 ZigBee 3.0 Smart Home Wireless Key Light Switch Fire Wire With NO Neutral For Xiaomi Mi Home homekit

Main feature

Note: The wall switch can connect the wire, can control any bulb throught the wire ; or control by phone APP .

while the wireless key cannot wired, only can control xiaomi smart bulb or light through phone APP

1 ) WIRELESS VERSION

Note: This switch has to work with zigbee Gateway hub to achieve smart remote control function

Features :

Cannot be wired, match with xiaomi or aqara smart bulb or light through ZigBee 3.0

* model ( wireless 1key : WXKG16LM , wireless 2key :WXKG17LM )

* Portable, realize controlling everywhere

* Wireless connection: ZiGBee 3.0

* Built-in CR2032 battery

* support APP : mi home , aqara home , homekit .

2) Aqara Smart Wall Switch E1 (No Neutral)

Single Rocker ( 1 key )

Model: QBKG38LM

Dimensions: 86 x 86 x 30.15mm

Wireless Connectivity: Zigbee 3.0

Rated Voltage: 220V--, 50Hz

Rated Power: Max 1100W, Min 3W

Operating Temperature:0°C~40°C

Operating Humidity: 5~95% RH. No condensation

Double Rocker (2 keys)

Model: QBKG39LM

Dimensions: 86 x 86 x 30.15mm

Wireless Connectivity: Zigbee 3.0

Rated Voltage: 220V~，50Hz

Rated Power: Max 1100W, Min 3W

Operating Temperature:0°C~40°C

Operating Humidity: 5~95% RH. No condensation

3) Aqara Smart Wall Switch E1 (With Neutral)

Single Rocker ( 1 key )

Model: QBKG40LM

Dimensions: 86 x 86x 30.15mm

Wireless Connectivity: Zigbee 3.0

Rated Voltage: Max 10A220V~, 50Hz

Rated Power: Max 1100W

Operating Temperature:0" C~40" C

Operating Humidity: 5~95% RH. No condensation

Double Rocker (2 keys)

Model: QBKG41LM

Dimensions: 86 x 86 x 30.15mm

Wireless Connectivity: Zigbee 3.0

Rated Voltage: Max 5A 220V~, 50Hz

Rated Power: Max 1100W

Operating Temperature:0" C~ 40 C

Operating Humidity: 5~95% RH. No condensation

FAQ:

--Aqara wireless switch E1 installation position and precautions?

The Agara wireless switch E1 can be affixed to a wall or placed on a desktop. As metal has a debilitating effect on wireless signals, it is not recommended to install wireless switches on metal doors. As a doorbell, a wireless switch can be mounted on the wall next to the metal door. (Please refer to the installation instructions for details)

In different indoor environments, the working distance between sub-devices and gateways is different. For use in everyday home environments, it is recommended that the distance between the sub-device and the gateway be no more than 10 m and that there be no more than two concrete walls in between.
