Description
【Please note:】Before ordering, please ensure that your address uses 110V or 220V voltage。
Order products according to the corresponding country address voltage, thank you very much!
The new upgrade version of high quality 8586 soldering station excellent introduction.
This is a brand new 2 in 1 SMD Rework Soldering Station 8586. Alloy metal body with highquality silicone shell features elegant appearanceand power saving. You can use hot air gun and soldering iron separately, with no interference with each other.
Because of the handle with sensor switch, the system can quickly access operating mode while gripping handle.Meanwhile, the system will transfer to standby mode while handle released. Especially suitable for mounting and reworking SMD components by hand. Really a must have!
750W 8586 2 In 1 Digital ESD Hot Air Gun Soldering Station Welding Solder Iron For IC SMD Desoldering Rework Tools 220v
Features:
Condition: Brand new
Hot air and hot iron 2in1 rework soldering station;
Extremely low noise and space saving design;
Dual LCD digital displays to show precision temperature;
SAMSUNG microcomputer control, quick warming-up;
PID technology to enhance temperature stability;
Adjust the airflow and temperature control rotation easily;
ntelligence self-detection function features safe personal operation;
Automatically stop rotation when the temperature is less than 70'C;
Handle with sensor switch features access operating mode when picks up or standby mode when lays down;
Automatic cooling function for effectively prolonging the heater's life and protecting the hot air gun;
ESD design of soldering iron to protect sensitive components;
International standard heater for convenient use and exchange;
High-quality resistance for durable use;
Plastic holder for placing the hot air gun;
Metal stand for keeping the iron from flammable materials;
Fits for heating shrink, drying, lacquer removal, viscidity removal, ice-out, pre-heating and glue soldering;
Voltage: 220V /110V/AC.
Hot Air Gun
Power : 700w
Resistant : <2Ω
Handpiece Size : <23mm
Temp Stability : ± 1'C
Fan : Brushless ball
Airflow : 120L/min(max)
Noise : <45dB
Temp Control : 100~450'C
Soldering Hot Iron
Power :60 W
Resistant : < 2Ω
Temp Stability : ± 1'C
Iron : ESD design
Heater Material : Nichrome
Temp Control : 200~480'C
Packing List:
1 x 8586 Soldering Station Host
1 x Hot air gun handle
1 x Electric iron handle
1 x Iron frame
1 x Wind gun rack
1 x power cable
4 X Nozzle
Suitable for : Unsoldering multiple components, such as SOIC ,CHIP, QFP, PLCC, BGA and temperature-sensitive components(especially for flat cables and cable connectors) ;
Applicable for hot contraction, heating, depainting, degluing, defrosting. Preheating and rubber soldering, and so forth.
![](https://ae01.alicdn.com/kf/Hce5feae96a6f4af582f7cc5e30587140O.jpg)
![](https://ae01.alicdn.com/kf/HTB1JR3YqKuSBuNjSsplq6ze8pXaO.jpg)
![](https://ae01.alicdn.com/kf/HTB1vb1NSVXXXXXhaXXXq6xXFXXXX.jpg?size=271226&height=1000&width=1000&hash=706616a47bc505a1bee11efcfccca3fb)
Due to different manufacturers batches, there may be differences in appearance, random to send any style.
