Description
PRODUCT OVERVIEW
U Shape Scissor Lift Table
DAXLIFTER® UL®-series E-type lift table is widely used in warehouses, workshops and other places with its economical price, high quality and durability. It is more convenient and practical to use the U type lift table for pallets of specific shapes, which can improve work efficiency. Equipped with a pump station with excellent performance, it provides sufficient power to ensure that the goods are lifted more smoothly.
SPECIFICATIONS
UL600 | UL1000 | UL1500 | |
Loadcapacity | 600kg | 1000kg | 1500kg |
Platform size | 1450*985mm | 1450*1140mm | 1600*1180mm |
Size A | 200mm | 280mm | 300mm |
Size B | 1080mm | 1080mm | 1194mm |
Size C | 585mm | 580mm | 580mm |
Max platform height | 860mm | 860mm | 860mm |
Min platform height | 85mm | 85mm | 105mm |
Base size L*W | 1335x947mm | 1335x947mm | 1335x947mm |
Weight | 207kg | 280kg | 380kg |
